GFRP Mesh Rebars are advanced composite reinforcement solutions engineered to meet modern structural and architectural requirements with high precision. Manufactured using high-strength glass fibers integrated with advanced polymer resin systems, GFRP mesh rebars are factory-produced in uniform grid patterns, ensuring consistent quality, dimensional accuracy, and reliable load distribution across concrete surfaces.
Unlike conventional steel reinforcement, GFRP Mesh Rebars are completely corrosion-resistant, non-magnetic, and electrically non-conductive. These properties make them highly suitable for applications exposed to moisture, chemicals, coastal environments, and aggressive conditions—where extended service life, structural durability, and minimal maintenance are critical.
GFRP Mesh Rebars are advanced composite reinforcement solutions engineered to provide superior strength, durability, and corrosion resistance in concrete applications. Manufactured using high-quality glass fibers combined with premium polymer resin systems, GFRP mesh rebars offer excellent tensile performance while maintaining a lightweight structure that is easy to transport, handle, and install. They serve as an efficient alternative to conventional steel welded mesh in demanding construction environments.
Unlike traditional steel reinforcement, GFRP Mesh Rebars are completely non-corrosive, non-magnetic, and electrically non-conductive. These inherent properties make them highly suitable for bridges, flyovers, marine and coastal structures, tunnels, industrial flooring, pavements, and infrastructure projects exposed to moisture, chemicals, salts, or aggressive environmental conditions.
Designed for long-term structural reliability, GFRP Mesh Rebars help extend the service life of concrete structures while significantly reducing maintenance and lifecycle costs. Their lightweight grid-based design enables faster installation, improved on-site safety, and uniform load distribution—making them a preferred reinforcement solution for modern infrastructure and sustainable construction projects.
| Property | Specification |
|---|---|
| Product Name | GFRP Mesh Rebar (Glass Fiber Reinforced Polymer) |
| Bar Diameter | 4mm, 6mm, 8mm, 10mm, 12mm (As per Mesh Design) |
| Mesh Opening / Grid Size | 50×50 mm, 100×100 mm, 150×150 mm, 200×200 mm (Custom Available) |
| Panel Size | Standard Panels or Custom Dimensions as per Project Requirement |
| Joint Type | Factory Molded / Resin-Bonded Intersections |
| Tensile Strength | ≥ 800 – 1000 MPa |
| Elastic Modulus | 45 – 60 GPa |
| Density | 1.9 – 2.1 g/cm³ |
| Corrosion Resistance | Excellent (100% Non-corrosive) |
| Thermal Conductivity | Low (Thermal Insulating) |
| Electrical Conductivity | Non-conductive |
| Magnetic Property | Non-magnetic |
| Surface Finish | Sand Coated / Textured for Improved Bond |
| Standard Compliance | ACI 440, ASTM D7957 / D7205, CSA S807 |
| Typical Applications | Slabs-on-Grade, Industrial Flooring, Pavements, Precast Panels, Marine Structures, Bridge Decks, Tunnel Linings |
